| Mfr. #: | 74ACT16244DLR |
|---|---|
| 製造商: | Texas Instruments |
| 描述: | Buffers & Line Drivers Tri-State 16-Bit |
| 生命週期: | 製造商新產品 |
| 數據表: | 74ACT16244DLR 數據表 |
Product belongs to the 74ACT series. Digi-ReelR Alternate Packaging is the packaging method for this product Weight of 0.021175 oz SMD/SMT Mounting-Style SSOP-48 Operational temperature range: -40°C ~ 85°C Surface Mount mounting type Output-Type: 3-State Number of channels: 16 Voltage Supply Range: 4.5 V ~ 5.5 V Supplier device package: 48-SSOP 4 element Buffer/Line Driver, Non-Inverting logic type 4 bits per element Power-off control: 1.2 W Maximum operating temperature of + 85 C Minimum operating temperature: - 40 C Polarity: Non-Inverting 80 uA is 92 nA. Maximum supply voltage of 5.5 V Minimum supply voltage is 4.5 V ACT logic type 8.7 ns at 5 V is 23 microseconds. High-Level-Output-Current of - 24 mA 24 mA low-level output current Number-of-Input-Lines: 16 Input Number-of-Output-Lines: 16 Output
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
74ACT16244DLR Specifications
