UCD7242RSJT

UCD7242RSJT Overview

This product is manufactured by Texas Instruments. Half-Bridge Drivers This device belongs to the High Side, Low Side type. The product can operate at a maximum temperature of SMD/SMT. VQFN-32 package/case type is utilized by this product. 2 Output is the number of outputs provided by this product. Output current: 10 A Supply Voltage - Min: 2.2 V Supply Voltage - Max: 18 V 5.2 W The minimum operating temperature of this product is - 40 C. The product can operate at a maximum temperature of + 125 C. Reel packaging for easy dispensing Output Voltage is - 0.3 V to + 3.6 V Texas Instruments is a trusted brand for quality electronics UCD9224EVM-464 is a versatile development platform for hardware and software 2.2 V to 18 V operating supply voltage range Gate Drivers product type 250 of 100 PMIC - Power Management ICs as subcategory 1. 0.002547 oz of Unit Weight

UCD7242RSJT Image

UCD7242RSJT Specifications

• Manufacturer: Texas Instruments
• Product Category: Gate Drivers
• RoHS: Y
• Product: Half-Bridge Drivers
• Type: High Side, Low Side
• Mounting Style: SMD/SMT
• Package / Case: VQFN-32
• Number of Drivers: 2 Driver
• Number of Outputs: 2 Output
• Output Current: 10 A
• Supply Voltage - Min: 2.2 V
• Supply Voltage - Max: 18 V
• Operating Supply Current: 6 mA
• Pd - Power Dissipation: 5.2 W
• Minimum Operating Temperature: - 40 C
• Maximum Operating Temperature: + 125 C
• Series: UCD7242
• Packaging: Reel
• Operating Temperature Range: - 40 C to + 125 C
• Output Voltage: - 0.3 V to + 3.6 V
• Technology: Si
• Brand: Texas Instruments
• Development Kit: UCD9224EVM-464
• Operating Supply Voltage: 2.2 V to 18 V
• Product Type: Gate Drivers
• Factory Pack Quantity: 250
• Subcategory: PMIC - Power Management ICs
• Unit Weight: 0.002547 oz
