AD7091RBCPZ-RL7 Overview

Product belongs to the AD7091R series. This product is categorized as Analog to Digital Converters Type: S/H ADC Digi-ReelR Alternate Packaging is the packaging method for this product SMD/SMT Mounting-Style LFCSP-10 The Single Ended for this product is CMOS/TTL. Operational temperature range: -40°C ~ 125°C Number of channels: 1 Channel Supplier device package: 10-LFCSP-WD (3x2) This product's 1M. Data-Interface: SPI, DSP 12 bits The Voltage-Supply-Analog is 2.09 V ~ 5.25 V. The Voltage Supply Digital for this product is 2.09 V ~ 5.25 V. Configuration S/H-ADC The architecture of this product is SAR . Supply is the reference type. 1 units Power-off control: 1 mW Maximum operating temperature of + 125 C Minimum operating temperature: - 40 C This product has a Power Consumption of 2.3 mW. Serial 4-Wire SPI interface type Signal-to-Noise Ratio of 69 dB The +/- 0.8 LSB of this product is 0.2%. Number-of-Converters: 1 Converter 1 MS/s Sampling Rate Analog supply voltage: 0 V to 2.5 V Digital Supply Voltage: 5.25 V Integral Nonlinearity: +/- 0.8 LSB Differential nonlinearity: +/- 0.3 LSB

AD7091RBCPZ-RL7 Image

AD7091RBCPZ-RL7 Specifications

• Manufacturer Analog Devices Inc.
• Product Category Data Acquisition - Analog to Digital Converters (ADC)
• Series AD7091R
• Product Analog to Digital Converters
• Type S/H ADC
• Packaging Digi-ReelR Alternate Packaging
• Mounting-Style SMD/SMT
• Package-Case LFCSP-10
• Input-Type Single Ended
• Operating-Temperature -40°C ~ 125°C
• Features -
• Number-of-Channels 1 Channel
• Supplier-Device-Package 10-LFCSP-WD (3x2)
• Sampling-Rate-Per-Second 1M
• Data-Interface SPI, DSP
• Number-of-Bits 12
• Voltage-Supply-Analog 2.09 V ~ 5.25 V
• Voltage-Supply-Digital 2.09 V ~ 5.25 V
• Configuration S/H-ADC
• Architecture SAR
• Number-of-Inputs 1
• Resolution 12 bit
• Reference-Type Supply
• Ratio-S-H:ADC 1899/12/30 1:01:00
• Number-of-A-D-Converters 1
• Pd-Power-Dissipation 1 mW
• Maximum-Operating-Temperature + 125 C
• Minimum-Operating-Temperature - 40 C
• Power-Consumption 2.3 mW
• Interface-Type Serial 4-Wire SPI
• SNR-Signal-to-Noise-Ratio 69 dB
• Gain-Error +/- 0.8 LSB
• Number-of-Converters 1 Converter
• Sampling-Rate 1 MS/s
• Analog-Supply-Voltage 0 V to 2.5 V
• Digital-Supply-Voltage 5.25 V
• INL-Integral-Nonlinearity +/- 0.8 LSB
• DNL-Differential-Nonlinearity +/- 0.3 LSB
