ADP5071AREZ

ADP5071AREZ Overview

Product belongs to the - series. Type: DC to DC Switching Regulator Tube Alternate Packaging is the packaging method for this product Wide - 40 C to + 125 C operating temperature range for diverse applications 20-TSSOP (0.173", 4.40mm Width) Exposed Pad Operational temperature range: -40°C ~ 125°C (TJ) Surface Mount mounting type Output-Type: Adjustable Product function is Step-Up, Step-Up/Step-Down. Supplier device package: 20-TSSOP-EP Number-of-Outputs: 2 Topology: Boost, SEPIC feedback This product features 'Frequency-Switching' at 1.2MHz, 2.4MHz for optimal performance. The Positive and Negative (Dual Rail). Minimum fixed output voltage is 0.8V, 1.6V . The value of No is included as a product attribute. The minimum input voltage is 2.85V. The 15V. Power-off control: Shutdown Maximum operating temperature of + 125 C Minimum operating temperature: - 40 C Output voltage: 2.85 V to 39 V 3.5 mA is 92 nA. Input Voltage Range: 2.85 V to 15 V Maximum Input Voltage: 15 V Output current: 2 A Switching frequency is 2.4 MHz The product's 2.85 V is 5.1 V. Load regulation is 0.0003 %/mA. Minimum supply voltage is 2.85 V

ADP5071AREZ Image

ADP5071AREZ Specifications

• Manufacturer Analog Devices Inc.
• Product Category PMIC - Voltage Regulators - DC DC Switching Regulators
• Series -
• Type DC to DC Switching Regulator
• Packaging Tube Alternate Packaging
• Operating-Temperature-Range - 40 C to + 125 C
• Package-Case 20-TSSOP (0.173", 4.40mm Width) Exposed Pad
• Operating-Temperature -40°C ~ 125°C (TJ)
• Mounting-Type Surface Mount
• Output-Type Adjustable
• Function Step-Up, Step-Up/Step-Down
• Supplier-Device-Package 20-TSSOP-EP
• Number-of-Outputs 2
• Topology Boost, SEPIC
• Frequency-Switching 1.2MHz, 2.4MHz
• Current-Output 1.2A, 2A
• Output-Configuration Positive and Negative (Dual Rail)
• Voltage-Output-Min-Fixed 0.8V, 1.6V
• Voltage-Output-Max ±39V
• Synchronous-Rectifier No
• Voltage-Input-Min 2.85V
• Voltage-Input-Max 15V
• Shutdown Shutdown
• Maximum-Operating-Temperature + 125 C
• Minimum-Operating-Temperature - 40 C
• Output-Voltage 2.85 V to 39 V
• Operating-Supply-Current 3.5 mA
• Input-Voltage 2.85 V to 15 V
• Input-Voltage-MAX 15 V
• Output-Current 2 A
• Switching-Frequency 2.4 MHz
• Input-Voltage-MIN 2.85 V
• Load-Regulation 0.0003 %/mA
• Supply-Voltage-Min 2.85 V
