| Mfr. #: | ESDALC14-1BF4 |
|---|---|
| 製造商: | STMicroelectronics |
| 描述: | TVS DIODE 5V 18V 0201 |
| 生命週期: | 製造商新產品 |
| 數據表: | ESDALC14-1BF4 數據表 |
Product belongs to the ESDA series. Type: Zener Digi-ReelR Alternate Packaging is the packaging method for this product This product's Termination-Style is ' SMD/SMT ' for easy integration into your design. 0201 (0603 Metric) Operational temperature range: -40°C ~ 150°C (TJ) Surface Mount mounting type Versatile General Purpose applications for maximum usability Number of channels: 1 Channel Supplier device package: 201 1 Bidirectional-Channels The Voltage-Reverse-Standoff-Typ is set at a maximum of 5V. The Voltage-Breakdown-Min is 13V. No Power-Line-Protection 22pF @ 1MHz Capacitance-Frequency Power-off control: 100 W Maximum operating temperature of + 150 C Minimum operating temperature: - 40 C Breakdown-Voltage: 13 V Clamping-Voltage: 18 V The Cd-Diode-Capacitance is 22 pF 5 V working voltage Polarity: Bidirectional 5 A of IPP, Peak Pulse, and Current 8 kV of Vesd-Voltage-ESD-Contact 15 kV Vesd-Voltage-ESD-Air-Gap
